Continuous cycle mixer. Hopper capacity 60 l.
Continuous cycle mixer for premixed products in bags. Simple to use, lightweight for handling and easy to clean. Available with rubber mixing chamber (Z-Clean version).
Common Characteristics
Simple to use continuous cycle mixer for premixed products. It is lightweight for handling and easy to clean at the end of the day. Equipped with an exclusive parallel-axis gearmotor and electronic starter, it is ideal for quickly mixing most dry premixed products with water. Easily adjust the loading / unloading height to allow for a minimal effort for loading.If provided with special optional kit, it is particularly suitable for mixing glues for laying external insulation and tiles.In combination with a plastering pump it can form a mixing and pumping unit.Z-Clean version, with rubber mixing chamber, reduces the accumulation of residual material in the mixing chamber and allows easier and faster cleaning at the end of the work. The rubber material reduces noise emissions and increases the operator’s comfort in closed environments.
Technical Data
| Parameter | Value |
|---|
| Drum capacity | 60
l |
| Rotations | 280
rpm |
| Weight | 85
kg |
| Electric motor power rate | 1.4
kW |
| Machine dimensions with el. motor L x H x W | 1380 х 950–1165 х 701
mm |
| Noise level | <65
dB(A) |
| Mixing performance | 17
l/min |
| Electric power supply | 230/50
V / Hz |
| Standard water pump | 0.45
kW |
