Suitable for removing water or similar relatively clean fluids from trenches, ditches, manholes or industrial sumps and excavations.
The pumps should not be used to pump flammable liquids.
Common Characteristics
• Cast-iron housing
• Bronze impeller
• Direct driven single stage centrifugal unit driven by powerful vane motor
• Integral oiler provides continuous lubrication
• Integral strainer, air inlet valve
• Double seals protect bearings and motor from water and mud
• No damage running without load
• Long life/low maintenance
• Extremely durable
• Safe to use in most environments
Technical Data
| Parameter | Value |
|---|
| Weight | 19.5/30.5
kg |
| Min opening needed | 210x230/230x240
mm |
| Min water depth | 22
mm |
| Max suction lift | -
m |
| Max head | 30.5/27.4
m |
| Air consumption | 47/51
l/s |
| Pressure | 6
bar |
| Air inlet | 3/4" NPT
|
| Air outlet | 1" NPT
|
| Max solid content | -
% |
| Recommended air supply hose size | 19/25
mm |
| Discharge inlet | -
|
| Discharge outlet | 2" NPT/2 1/2" BSP
|
| Power | 2.2/2.9
kW |
| Part number | T022224/T022185
|
