Band saw IMET CUBO 300 NC FLAT
Common Characteristics
CUBO 300 NC FLAT is an automatic bandsaw with CNC suitable to be a professional working tool for batch production for tubes, bars, profiles and solids. The machine bow rotation is manual while the automatic feeder is integrated. Thanks to INDUSTRY 4.0 READY optional, the user can control its machine remotely (or with the 7" integrated touch screen display)
Technical Data
| Parameter | Value |
|---|
| Cutting capacity at 0° Round/Sq/Rect | 255/230/300х180
mm |
| Cutting capacity at 45° for Round/Sq/Rect | 210/190/200х160
mm |
| Cutting capacity at 60° for Round/Sq/Rect | 135/110/130х100
mm |
| Cutting capacity bundle | 250x130
mm |
| Cutting capacity at 0° solids (C45) | 180
mm |
| Blade size | 2765x27x0.9
mm |
| Blade speed | 18-100
m/min |
| Blade motor | 1.5
kW |
| Minimum scrap end | 230
mm |
| Weight | 1000
kg |
| Size | 2030x1830x1830
mm |
| Hydraulic unit tanc capacity | 20
l |
