Cordless Rail Drilling Machine.
Common Characteristics
This battery-operated, very powerful, compact, and lightweight rail drilling machine is a perfect solution for outdoor work in remote areas, where no power supply is available.
Fast positioning, quick clamping, and instant unlocking mechanisms make it a useful and safe device.
PRO-36R Battery enables drilling in rails of any standard by means of 2 pcs of optional rail profile templates and 1 pc of hole center positioned, to be chosen by customers from a comprehensive range of auxiliary accessories dedicated to a variety of types of rails.
Features & benefits:
• ATEX-approved materials. Safe for use in Ex zones and environments with hazardous, flammable, or combustible vapors,
liquids, dust, or residues.
• Strong permanent magnet. Secures the drill without the need for an electric supply.
• Permanent magnetic base with V-shaped prismatic foot. Enables drilling on pipes from 250 mm upwards.
• Innovative sliding ON/OFF pneumatic motor switch. Provides compressed air to the pneumatic motor.
• Mechanical safety lock. Prevents accidental motor activation.
• Magnet ON/OFF indicator. Enhances safety.
• Ultra-low design. Perfect for space-restricted areas, with a height of only 185 mm.
• Compact size and lightweight. Ideal for site work.
Technical Data
| Parameter | Value |
|---|
| Motor Speed (under load) | 260
rpm |
| Motor Power | 450
W |
| Weight | 14.5
kg |
| Max milling capacity TCT/HSS | 36
mm |
| Max drilling capacity | 16
mm |
| Stroke | 40
mm |
| Max depth of cut | 30
mm |
| Voltage | 18
V |
| Tool holder | 19 Weldon
mm |
