| Motor Speed (under load) | 240
rpm |
| Motor Power | 800
W |
| Weight | 15
kg |
| Max milling capacity TCT/HSS | 40
mm |
| Max drilling capacity | 16
mm |
| Stroke | 40
mm |
| Max depth of cut | 25
mm |
| Magnetic clamping force | 714/7000
kgf/N |
| Magnet Base Dimensions | 75x188x56
mm |
| Min. Workpiece Thickness | 10
mm |
| Tool holder | 19 Weldon
mm |
| Air consumption | 1400
l/min |
| Pressure | 6
bar |
| Minimum diameter of air hoses | 13
mm |
| Required ambient temperature | 0 – 40
° |
| Minimum pipe diameter | 250
mm |
| Potentially explosive atmosphere | II 2G Ex h IIC 135°C (T4) Gb II 2D Ex h IIIB T135°C Db
|
| Overall dimensions L x W x H | 600x205x185
|
