Visibility at a new level in 3 x 360°.
Common Characteristics
Highly precise CAL Guard monitoring and use via remote control with a Bluetooth®-connected smartphone through an app. High visibility ensured by high-power diodes.
3 x 360° lines allow simultaneous horizontal and vertical leveling for highly efficient work.
This line laser is designed for flooring installation, window fitting, shelf mounting, drainage pipe installation, drywall framing, and tile laying.
With the Dual Power Source of the GLL 3-80 C Professional, it can operate using either a 12 V lithium-ion battery or standard alkaline batteries for added flexibility.
It can self-level on uneven surfaces up to +/- 4° in less than 4 seconds with excellent accuracy of ± 0.2 mm/m*/** and has a working range of up to 120 m when used with the optional LR 6 or LR 7 Professional receiver.
Technical Data
| Parameter | Value |
|---|
| Корда: 630 - 650 nm, < 10mW
nm, mW |
| -10 – 40 °C
°C |
| -20 – 70 °C
°C |
| 2
|
| 30
m |
| до 120 m
m (диаметър) |
| +/- 0,2 mm/m*/** (*за четирите хоризонтални пресечни точки ; **плюс отклонение, зависимо от използването)
mm/m |
| ± 4°
% (°) |
| 4
s |
| IP 54 *** (***освен литиево-йонна акумулаторна батерия и адаптер за AA1 батерия)
|
| 12 V литиево-йонна акумулаторна батерия
4 x 1,5-V-LR6 (AA)
|
| 8 ч. (Li-Ion) и 6 ч. (4 x AA) в трилинеен режим
|
| 1/4", 5/8"
|
| Червен
|
| 0.9
kg |
