Welding inverrter BOHLER, URANOS 2700 SMC SMART

URANOS 2700 SMC SMART - MIG/MAG welding machine
Common Characteristics
"Green @ wave" inverter technology for high energy efficiency and perfect control over all welding phases
Heavy duty and enviromental conditions, high service life
CAN fieldbus digital communication protocol system (very high speed and high reliability digital communication)
Software based controls can be upgraded as new features become available
High temperature, shockproof, abrasion resistant plastic case
Air flow ducting and fully encapsulated PC board to avoid dust contamination
Linear controlled fan on demand
Energy-saving inverter technology (built-in P.F.C. - power factor controller)
Built-in wire feeder unit (2/4 rolls drive)
O 200/300 mm wire spool compatible
Welding polarity switch device
Full digital and user-friendly control panel
Welding parameters digital display
Last job settings auto-storage at switch-off
User-defined welding program storage capability (64 free memory locations) (URANOS 2700 SMC Exclusive)
Lock-unlock function key protected by password
Ideal for stick welding with multiple types of popular electrodes
Built-in adjustable arc control features (hot start, arc force, antisticking)
Synergic setting for optimal stick welding with all types of electrodes
Reduced electromagnetic interference with lift start TIG welding
2/4 step operating mode
Arc dynamic adjustment
Perfect arc ignition (soft start - motor slope)
Burn-back and droplet detachment correction
Crater filler operating mode (URANOS 2700 SMC
MIG/MAG bilevel (URANOS 2700 SMC Smart/Exclusive)
Euro adaptor - U/D MIG/MAG torch compatible (URANOS 2700 SMC Exclusive)
Push-pull torch device (URANOS 2700 SMC Exclusive)
Controlled cooling operations
Technical Data
Voltage (50/60 Hz)3 x 400  V
Slow blow line fuse16  A
Adjustment range MIG/MAG3-270  A
Adjustment range TIG3-270  A
Duty cycle MMA 40%270  A
Duty cycle MMA 60%250  A
Duty cycle MMA 100%230  A
Duty cycle TIG 50%270  А
Duty cycle TIG 60%260  А
Duty cycle TIG 100%240  А
Duty cycle MIG/MAG 45%270  А
Duty cycle MIG/MAG 60%250  А
Duty cycle MIG/MAG 100%230  А
Open circuit voltage30-92  V
Insulation class23  S
Dimensions620x270x460  mm
